Skyworks is pleased to introduce Si86Px Digital Isolators with Integrated Power.

Introducing the new Si86Px family of digital isolators with integrated power, a compact solution that combines high‑performance digital isolation with an integrated isolated dc‑dc converter and matched miniature transformer. Designed for industrial and automotive electronics, the Si86Px simplifies isolated system design while reducing PCB area, BOM count, and overall design complexity.

The Si86Px addresses a critical challenge for system designers: generating high‑quality isolated power in applications where board space is limited or where no power source is readily available on the isolated side. By integrating signal and power isolation into a single package, the Si86Px can help reduce time to market while providing a well-regulated power source for sensitive components such as ADCs and sensors.

Built for Demanding Industrial and Automotive Applications

• Designed for harsh environments:  operates over a wide –40°C to +125°C temperature range and provides 75 kVrms isolation, making it well suited for industrial automation, factory equipment, and automotive applications
• Simplified system design: integrated power architecture and low‑EMI design help designers meet system‑level performance and compliance requirements with fewer external components
• Significant tighter load regulation: delivers 1% typical load regulation, compared to 1% typical for comparable integrated power isolators, providing up to 10× better regulation for powering sensitive analog components
• Higher data‑rate capability: supports up to 150 Mbps, exceeding devices rated at 100 Mbps or below for faster and more responsive system control

• Robust data integrity: features 100 kV/µs common‑mode transient immunity (CMTI) for reliable operation in harsh electrical noise

Features

• Dual & Quad high-speed isolators with integrated/isolated power (requiring only decoupling caps)

• 500 mW output power with 43% efficiency @ 5.0 V / 5.0 V

• VIN/VOUT options:

• 3.3V to 3.3V (60mA capable),

• 3.3V - 5.0V to 3.3V (wide input rage),

• 5.0V to 3.3V (125mA capable), and 5.0V to 5.0V (100mA capable)

• CMTI: 100 kV/µs (min)

• Isolation ratings compliant to VDE basic, CSA, UL, CQC

• 3.75 kVRMS VISO, 650 Vpeak working voltage

• Hysteretic control (100- 150 kHz Fs) & dithering for low EMI

• Compliant to CISPR-32, FCC Class B

• TA = -40 °C to +125 °C

• RoHS compliant WB SOIC-16 & SOIC-20 packages
